Submersible sludge pump XJS 110

Smooth operators

The submersible sludge pump XJS 110 is ideal for pumping sludge and water mixed with solids. Pumps with built in AquaTronic unit will always have correct direction of impeller rotation, ensuring peak performance and reduced wear. 50 Hz: head max 36 meters, flow max 31 l/s. 60 Hz: head max 40 meters (131 feet), flow max 30 l/s (476 gpm).

Submersible sludge pump XJS 110
Main benefits
  • Plug-and-pump installation without having to worry about overheating.
  • Pumps with a built-in AquaTronic unit will adjust incorrect phase order, ensuring correct impeller rotation.
  • A wide range of pumps, up to 11 kW, makes it easy to find a solution for any pumping need.
  • Clog-free pumping with pumps designed for pumping sludge and water mixed with solids.
  • Non-overloading performance with two different impellers for each pump model. The small impeller allows the pump to run in low-level applications.
  • Serviceability with modular design. Pumps with a built-in AquaTronic can be checked without disassembly, using its service software.
Models
  • XJS 110 D -170 3-phase 50 Hz
  • XJS 110 D -170 AT* 3-phase 50 Hz
  • XJS 110 D -195 3-phase 50 Hz
  • XJS 110 D -195 AT* 3-phase 50 Hz
  • XJS 110 D -155 3-phase 60 Hz
  • XJS 110 D -155 AT* 3-phase 60 Hz
  • XJS 110 D -166 3-phase 60 Hz
  • XJS 110 D -166 AT* 3-phase 60 Hz

Weight: 80 kg (176 lb)

*AquaTronic: Built in electronic pump control.

AquaTronic built-in electronic supervision
Level sensor, AquaPlug or AquaTronic control panel and service diagnostics program are monitoring options for pumps with built-in AquaTronic

AquaTronic option

The AquaTronic unit (AT) replaces the built-in contactor in the basic pump configurations and ensures that the motor always rotates correctly, no matter how the phases are connected. Key benefits of the AquaTronic unit include:

  • Correction of motor rotation if phases are improperly connected
  • Run mode (no panel needed)
  • Integrated start equipment (direct or soft start depending on pump model)
  • Motor protection against high temperature, high amperage and missing phase
  • Anti-clog function



If the pump is also equipped with an optional level sensor, AquaTronic provides:

  • Precise level control
  • Protection against dry running
  • Energy save mode (energy is saved through stopping at dry run and starting by level sensor)



AquaTronic service diagnostic program

Connecting a PC to the AquaTronic unit via USB cable provides access to the service diagnostic program, which offers:

Pump status data, pump operating history, pump failure history, pump service/maintenance history, digital manual and spare part documentation



AquaPlug and AquaTronic control panel

AquaPlug and AquaTronic control panel are options that combine with AquaTronic to provide additional alarm and start/stop functions, as well as indications for important parameters.

Benefits

Plug-and-pump installation

Plug in without having to worry about overheating. Built-in contactor and thermal sensors protect the motor from overheating. Pumps with a built-in AquaTronic unit will adjust electronically for incorrect phase order, ensuring correct impeller rotation.

Reliable and trouble-free operation

The XJS is perfect for pumping sludge and water mixed with solids as it is equipped with a free-flow vortex impeller and a pump volute. The pump design, the robust construction and the premium materials ensure high wear resistance, and the impeller is available in different sizes to meet your specific requirements.

Serviceability

The modular design of the pump range reduces costs by ensuring maximum pump availability with a smaller spare parts inventory. The condition of a pump with a built-in AquaTronic unit can be rapidly checked without disassembly, using its service software.

Saves energy and the environment

The high-efficiency motor and hydraulics are combined with low-friction bearings to reduce power losses. You achieve low total energy costs and minimize your carbon footprint. Environmentally safe white oil is used in the oil casing for easy inspection of seal conditions.

50 Hz
Electric submersible pump  XJS 110
Maximum submergence 20 m
Protection class IP 68
Max. temperature of pumped medium at max. power input and continuous duty 40ºC
Max. media density 1,100 kg/m3
pH of the pumped medium 5-8
Free passage 48 x  60 mm
Max number of starts 30/hour
Motor rating P2 11.8 kW
Speed 2,920 rpm
Power cable 20 m type H07RN8-F
60 Hz
Electric submersible pump  XJS 110
Maximum submergence 20 m
Protection class IP 68
Max. temperature of pumped medium at max. power input and continuous duty 40ºC
Max. media density 1,100 kg/m3
pH of the pumped medium 5-8
Free passage 48 x 60 mm
Max number of starts 30/hour
Motor rating P2 13.5 kW
Speed 3,500 rpm
Power cable 20 m type H07RN8-F
60 Hz US
Electric submersible pump  XJS 110
Maximum submergence 65 ft
Protection class IP 68
Max. temperature of pumped medium at max. power input and continuous duty 104ºF
Max. media density 0.0397 lb/inch3
pH of the pumped medium 5-8
Free passage 1 7/8” x 2 3/8”
Max number of starts 30/hour
Motor rating P2 18 Hp
Speed

3,500 rpm

Power cable 65 ft type AWG
Case studies
  • Proven expertise in dewatering pumps rental
    Neptune is specialized in the rental and sale of pumping equipment for clean water and wastewater. Its rental fleet includes 90% dewatering pumps and 10% sewage pumps. Sulzer as a partner provides proven solutions in wastewater and dewatering.

  • Complete dewatering pumps fleet for mining
    Robust Sulzer dewatering equipment endures tough mine environment. Built-in intelligence in submersible drainage and sludge pumps XJ/XJS prevents loss of capacity due to connection errors and provides early warnings that allow service at lower cost.
