Light wastewater pump type ABS MF 154-804 | Sulzer

Main benefits

With or without automatic level control
Excellent solids handling with vortex impeller and a large free passage (solids from 20 to 60 mm)
3 or 10 m cable
Compact shape, fittings for easy mounting, and small sump requirements enable a quick and cost-effective installation
For locations such as building sites, the MF 354, MF 504, and MF 804 are available in a VO version, featuring a protective screen, elbow, and hose coupling

Main applications

Removal of fecal-free wastewater and rainwater
Pumping of flooded cellars
Removal of nuisance water from gullies or pedestrian underpasses
Pumping of fluids containing gaseous or abrasive particles, thanks to vortex hydraulics

Main design features

Thermal sensors
Oil-lubricated mechanical seal medium side; oil-lubricated lip seal at motor side
Stainless steel rotor shaft supported in lubricated-for-life ball bearings
Easy fit plug-in cable connection
Single-phase fitted with Schuko plug; three-phase with CEE plug

Key characteristics

Capacities	58 m³/h (255 US gpm)
Heads	16 m (52 ft)
Temperatures	40°C / max. 60°C for five minutes
Discharge sizes	G 1¼”–2” (MF 154W - 804D). DN 65 (MF 565W, 665D)
Maximum speed of rotation	2,900 min^-1
