Main benefits
  • Pumps down to 3 mm when the detachable suction ring is fitted into the screen
  • Easy installation with Schuko plug and 10 m cable
  • Automatic operation with built-in float switch for reliable operation
  • Backflow is prevented with built-in check valve
  • Fits in small sumps from 300 x 300 mm
  • Suitable for both manual and automatic operation with the unique hand/auto switch
Main applications
  • Domestic and commercial wastewater without toilet waste
  • Drainage of pits and flooded cellars
Main design features
  • Thermal sensors
  • Three lip seals lubricated by a grease chamber
  • Protection type IP 68
  • Stainless steel rotor shaft supported in lubricated-for-life ball bearings
  • Motor housing made of corrosion-resistant material, and the outer jacket and impeller of durable plastics
  • 60 Hz version available with approval (UL, CSA)
Key characteristics
Capacities Up to 12 m3/h / 52 US gpm
Heads 8.5 m / 28 ft
Temperatures 40°C up to 60°C / 104°f up to 140°F
Discharge sizes G 1¼”
Maximum speed of rotation 2,900 rpm
